20mm Magnetic Track System
Surface mounted, trimless recessed and board recessed 20mm track rails for residential and commercial magnetic track lighting projects. Compatible with 22Y and 20B series LED modules.
Three Installation Methods
Choose the right 20mm track for your ceiling type and project requirements.
▭ Surface Mounted
Direct ceiling mount, no cutting needed. Ideal for renovation projects and concrete ceilings. Quick installation with minimal preparation work.
- Thickness: 1.5mm / 2.0mm
- Colors: Black / White
- Best for: Renovations, concrete ceilings, cost-sensitive projects
⊟ Trimless Recessed
Seamless ceiling integration for premium interiors. Perfect for projects where a clean, uninterrupted ceiling surface is required.
- Thickness: 1.6mm
- Colors: Black
- Best for: Villas, hotels, high-end residences
⊞ Board Recessed
Neat edge for board ceilings in commercial and residential projects. Provides a clean finish that integrates with drywall or panel ceilings.
- Thickness: 1.6mm / 2.5mm
- Colors: Black
- Best for: Commercial spaces, offices, residential board ceilings
| Installation Method | Thickness | Color |
|---|---|---|
| Surface Mounted Track 20mm | 1.5mm / 2.0mm | Black / White |
| Trimless Recessed Track 20mm | 1.6mm | Black |
| Board Recessed Track 20mm | 1.6mm / 2.5mm | Black |
22Y Series — High-End
Premium series with built-in driver and SMD Custom chips. CRI ≥90 for demanding commercial and hospitality projects. The recommended choice for projects requiring superior color rendering and reliable performance.
| Model | Power | Dimension | CRI | Beam Angle | CCT |
|---|---|---|---|---|---|
F22Y-P30-14W |
14W | 300×23×25mm | ≥90 | 120° | 3000K / 4000K / 6000K |
F22Y-P60-24W |
24W | 600×23×25mm | ≥90 | 120° | 3000K / 4000K / 6000K |
Grid Light
| Model | Power | Dimension | CRI | Beam Angle | CCT |
|---|---|---|---|---|---|
G22Y-16T-18W |
18W | 300×23×25mm | ≥90 | 24° | 3000K / 4000K / 6000K |
G22Y-32T-24W |
24W | 600×23×25mm | ≥90 | 24° | 3000K / 4000K / 6000K |
Folding Grid Light
| Model | Power | Dimension | CRI | Beam Angle | CCT |
|---|---|---|---|---|---|
Z22Y-8T-10W |
10W | 160×23×137mm | ≥90 | 24° | 3000K / 4000K / 6000K |
Z22Y-16T-24W |
24W | 300×23×137mm | ≥90 | 24° | 3000K / 4000K / 6000K |
Track Spot Light
| Model | Power | Dimension | CRI | Beam Angle | CCT |
|---|---|---|---|---|---|
D500-10W |
10W | Φ50×120mm | ≥90 | 24° | 3000K / 4000K / 6000K |
20B Series — Cost-Effective
Cost-effective option for budget-conscious projects where ultra-high CRI is not critical. External driver required. Reliable performance at a competitive price point for large-scale installations.
| Model | Power | Dimension | CRI | Beam Angle | CCT |
|---|---|---|---|---|---|
F20B-P30-12W |
12W | 300×23×25mm | ≥80 | 120° | 3000K / 4000K / 6000K |
F20B-P60-24W |
24W | 600×23×25mm | ≥80 | 120° | 3000K / 4000K / 6000K |
Grid Light
| Model | Power | Dimension | CRI | Beam Angle | CCT |
|---|---|---|---|---|---|
G20B-8T-12W |
12W | 300×23×25mm | ≥80 | 24° | 3000K / 4000K / 6000K |
G20B-16T-24W |
24W | 600×23×25mm | ≥80 | 24° | 3000K / 4000K / 6000K |
Folding Grid Light
| Model | Power | Dimension | CRI | Beam Angle | CCT |
|---|---|---|---|---|---|
Z20B-8T |
10W | 160×23×137mm | ≥80 | 24° | 3000K / 4000K / 6000K |
Z20B-16T |
20W | 300×23×137mm | ≥80 | 24° | 3000K / 4000K / 6000K |
Track Spot Light
| Model | Power | Dimension | CRI | Beam Angle | CCT |
|---|---|---|---|---|---|
D500B-10W |
10W | Φ50×120mm | ≥80 | 24° / 36° | 3000K / 4000K / 6000K |
Connectors & Accessories
Complete your 20mm track system with matching connectors, power modules and mounting accessories.
∟ L-Shape Connector
90° corner connection for continuous track runs around room perimeters or creating L-shaped layouts.
✚ Cross Connector
4-way junction for complex ceiling layouts. Enables grid-style track configurations for multi-directional lighting.
┬ T-Shape Connector
3-way junction for branching track runs. Ideal for creating T-intersections in open-plan ceiling designs.
⌞ Wall Corner Connector
Ceiling-to-wall transition connector. Enables track to turn from the ceiling onto a wall for vertical lighting applications.
⚡ Power Input Module
Straight input module for connecting the 48V DC driver to the track system. Available in end-feed and middle-feed configurations.
⏤ End Caps & Suspension Kits
Finish and mount track ends. End caps provide a clean termination while suspension kits enable pendant mounting for high ceilings.
Compatible LED Modules
Explore the complete range of LED modules designed for the 20mm magnetic track system.
◐ Flood Light
Uniform linear lighting for general illumination in residential, retail and office projects. Beam angle 120° for wide coverage.
- 22Y: 14W / 24W (Built-in driver)
- 20B: 12W / 24W (External driver)
- CRI ≥90 (22Y) / ≥80 (20B)
▦ Grid Light
Low-glare linear lighting for offices, hotels and premium commercial interiors. Anti-glare design with 24° beam angle.
- 22Y: 18W / 24W (Built-in driver)
- 20B: 12W / 24W (External driver)
- CRI ≥90 (22Y) / ≥80 (20B)
◱ Folding Grid Light
Flexible angle adjustment with low-glare design for display and hospitality lighting. Compact form factor with folding mechanism.
- 22Y: 10W / 24W (Built-in driver)
- 20B: 10W / 20W (External driver)
- CRI ≥90 (22Y) / ≥80 (20B)
◎ Track Spot Light
Adjustable accent lighting for retail displays, showrooms, galleries and villas. Compact cylindrical design with precise beam control.
- 22Y: 10W, Φ50×120mm (Built-in driver)
- 20B: 10W, Φ50×120mm (External driver)
- CCT: 3000K / 4000K / 6000K
